Description
| Rim (inch) | Size | Service Index | Tread Depth (32nd) | Standard Rim | Section Width (inch) | Overall Diameter (inch) | Max. Load (lbs) | Max. Air Pressure (psi) | UTQG | ||
|---|---|---|---|---|---|---|---|---|---|---|---|
| 15″ | 225/70R15 | 100T | 10.3 | 6.5J | 9 | 27.4 | 1764 | 44 | 500 | A | A |
| 235/70R15 | 103T | 10.3 | 7.0J | 9.4 | 28 | 1930 | 44 | 500 | A | A | |
| 265/70R15 | 112T | 10.3 | 8.0J | 10.7 | 29.6 | 2469 | 44 | 500 | A | A | |
| 215/75R15 | 100T | 10.3 | 6.0J | 8.5 | 27.7 | 1764 | 44 | 500 | A | A | |
| 225/75R15 | 102T | 10.3 | 6.0J | 8.8 | 28.3 | 1874 | 44 | 500 | A | A | |
| 235/75R15 | 105H | 10.3 | 6.5J | 9.3 | 28.9 | 2039 | 44 | 500 | A | A | |
| 265/75R15 | 112T | 10.3 | 7.5J | 10.5 | 30.7 | 2469 | 44 | 500 | A | A | |
| 16″ | 255/65R16 | 109H | 10.3 | 7.5J | 10.2 | 29.1 | 2270 | 44 | 500 | A | A |
| 205/70R16 | 97T | 10.3 | 6.0J | 8.2 | 27.7 | 1609 | 44 | 500 | A | A | |
| 215/70R16 | 100T | 10.3 | 6.5J | 8.7 | 27.9 | 1764 | 44 | 500 | A | A | |
| 225/70R16 | 103H | 10.3 | 6.5J | 9 | 28.4 | 1929 | 44 | 500 | A | A | |
| 235/70R16 | 106H | 10.3 | 7.0J | 9.4 | 29 | 2095 | 44 | 500 | A | A | |
| 245/70R16 | 107T | 10.3 | 7.0J | 9.8 | 29.5 | 2149 | 44 | 500 | A | A | |
| 255/70R16 | 111H | 10.3 | 7.5J | 10.2 | 30.1 | 2403 | 44 | 500 | A | A | |
| 265/70R16 | 112T | 10.3 | 8.0J | 10.7 | 30.6 | 2469 | 44 | 500 | A | A | |
| 275/70R16 | 114T | 10.3 | 8.0J | 11 | 31.2 | 2601 | 44 | 500 | A | A | |
| 225/75R16 | 104H | 10.3 | 6.0J | 8.8 | 29.3 | 1984 | 44 | 500 | A | A | |
| 235/75R16 | 108T | 10.3 | 6.5J | 9.3 | 29.8 | 2205 | 44 | 500 | A | A | |
| 245/75R16 | 111T | 10.3 | 7.0J | 9.8 | 30.5 | 2403 | 44 | 500 | A | A | |
| 265/75R16 | 116T | 10.3 | 7.5J | 10.5 | 31.7 | 2756 | 44 | 500 | A | A | |
| 17″ | 215/60R17 | 96H | 10.3 | 6.5J | 8.7 | 27.2 | 1565 | 44 | 500 | A | A |
| 225/60R17 | 99T | 10.3 | 6.5J | 9 | 27.6 | 1709 | 44 | 500 | A | A | |
| 235/60R17 | 102T | 10.3 | 7.0J | 9.4 | 28.1 | 1874 | 44 | 500 | A | A | |
| 255/60R17 XL | 110V | 10.3 | 7.5J | 10.2 | 29.1 | 2337 | 51 | 500 | A | A | |
| 265/60R17 | 108T | 10.3 | 8.0J | 10.7 | 29.5 | 2205 | 44 | 500 | A | A | |
| 275/60R17 | 110T | 10.3 | 8.0J | 11 | 30 | 2337 | 44 | 500 | A | A | |
| 215/65R17 | 99T | 10.3 | 6.5J | 8.7 | 28 | 1709 | 44 | 500 | A | A | |
| 225/65R17 | 102H | 10.3 | 6.5J | 9 | 28.5 | 1875 | 44 | 500 | A | A | |
| 235/65R17 | 104H | 10.3 | 7.0J | 9.4 | 29.1 | 1985 | 44 | 500 | A | A | |
| 245/65R17 | 107T | 10.3 | 7.0J | 9.8 | 29.5 | 2149 | 44 | 500 | A | A | |
| 255/65R17 | 110H | 10.3 | 7.5J | 10.2 | 30.1 | 2337 | 44 | 500 | A | A | |
| 265/65R17 | 112H | 10.3 | 8.0J | 10.7 | 30.6 | 2469 | 44 | 500 | A | A | |
| 275/65R17 | 115T | 10.3 | 8.0J | 11 | 31.1 | 2679 | 44 | 500 | A | A | |
| 285/65R17 | 116H | 10.3 | 8.5J | 11.5 | 31.6 | 2756 | 44 | 500 | A | A | |
| 235/70R17 | 109T | 10.3 | 7.0J | 9.4 | 30 | 2271 | 44 | 500 | A | A | |
| 245/70R17 | 110T | 10.3 | 7.0J | 9.8 | 30.6 | 2337 | 44 | 500 | A | A | |
| 255/70R17 | 112T | 10.3 | 7.5J | 10.2 | 31.1 | 2469 | 44 | 500 | A | A | |
| 265/70R17 | 115H | 10.3 | 8.0J | 10.7 | 31.7 | 2679 | 44 | 500 | A | A | |
| 255/75R17 | 115S | 10.3 | 7.0J | 10 | 32 | 2679 | 44 | 500 | A | A | |
| 18″ | 215/55R18 | 95V | 10.3 | 7.0J | 8.9 | 27.3 | 1521 | 44 | 500 | A | A |
| 225/55R18 | 98V | 10.3 | 7.0J | 9.2 | 27.8 | 1653 | 44 | 500 | A | A | |
| 235/55R18 | 100V | 10.3 | 7.5J | 9.6 | 28.1 | 1764 | 44 | 500 | A | A | |
| 245/55R18 | 103V | 10.3 | 7.5J | 10 | 28.6 | 1929 | 44 | 500 | A | A | |
| 255/55R18 XL | 109V | 10.3 | 8.0J | 10.4 | 29 | 2271 | 51 | 500 | A | A | |
| 225/60R18 | 100H | 10.3 | 6.5J | 9 | 28.6 | 1764 | 44 | 500 | A | A | |
| 235/60R18 | 103V | 10.3 | 7.0J | 9.4 | 29.1 | 1929 | 44 | 500 | A | A | |
| 245/60R18 | 105T | 10.3 | 7.0J | 9.8 | 29.6 | 2039 | 44 | 500 | A | A | |
| 255/60R18 XL | 112V | 10.3 | 7.5J | 10.2 | 30 | 2469 | 51 | 500 | A | A | |
| 265/60R18 XL | 114V | 10.3 | 8.0J | 10.7 | 30.5 | 2601 | 51 | 500 | A | A | |
| 285/60R18 | 116H | 10.3 | 8.5J | 11.5 | 31.5 | 2756 | 44 | 500 | A | A | |
| 225/65R18 | 103H | 10.3 | 6.5J | 9 | 29.5 | 1929 | 44 | 500 | A | A | |
| 235/65R18 | 106H | 10.3 | 7.0J | 9.4 | 30 | 2094 | 44 | 500 | A | A | |
| 255/65R18 | 111T | 10.3 | 7.5J | 10.2 | 31.1 | 2403 | 44 | 500 | A | A | |
| 265/65R18 | 114T | 10.3 | 8.0J | 10.7 | 31.5 | 2601 | 44 | 500 | A | A | |
| 275/65R18 | 116T | 10.3 | 8.0J | 11 | 32.1 | 2756 | 44 | 500 | A | A | |
| 255/70R18 | 113T | 10.3 | 7.5J | 10.2 | 32.1 | 2535 | 44 | 500 | A | A | |
| 265/70R18 | 116H | 10.3 | 8.0J | 10.7 | 32.6 | 2756 | 44 | 500 | A | A | |
| 19″ | 275/45R19 XL | 108V | 10.3 | 9.0J | 10.7 | 28.8 | 2205 | 51 | 500 | A | A |
| 235/50R19 | 99V | 10.3 | 7.5J | 9.6 | 28.3 | 1709 | 44 | 500 | A | A | |
| 255/50R19 XL | 107V | 10.3 | 8.0J | 10.4 | 29.1 | 2149 | 51 | 500 | A | A | |
| 225/55R19 | 99V | 10.3 | 7.0J | 9.2 | 28.8 | 1709 | 44 | 500 | A | A | |
| 245/55R19 | 103V | 10.3 | 7.5J | 10 | 29.6 | 1929 | 44 | 500 | A | A | |
| 255/55R19 XL | 111V | 10.3 | 8.0J | 10.4 | 30 | 2403 | 51 | 500 | A | A | |
| 255/60R19 | 109H | 10.3 | 7.5J | 10.2 | 31.1 | 2271 | 44 | 500 | A | A | |
| 20″ | 275/40R20 XL | 106V | 10.3 | 9.5J | 10.9 | 28.7 | 2094 | 51 | 500 | A | A |
| 275/45R20 XL | 110V | 10.3 | 9.0J | 10.7 | 29.8 | 2337 | 51 | 500 | A | A | |
| 245/50R20 | 102V | 10.3 | 7.5J | 10 | 29.7 | 1874 | 44 | 500 | A | A | |
| 265/50R20 XL | 111V | 10.3 | 8.5J | 10.9 | 30.5 | 2403 | 51 | 500 | A | A | |
| 285/50R20 XL | 116H | 10.3 | 9.0J | 11.7 | 12.2 | 2756 | 51 | 500 | A | A | |
| 235/55R20 | 102H | 10.3 | 7.5J | 9.6 | 30.2 | 1874 | 44 | 500 | A | A | |
| 255/55R20 | 107H | 10.3 | 8.0J | 10.4 | 31 | 2271 | 44 | 500 | A | A | |
| 275/55R20 XL | 117V | 10.3 | 8.5J | 11.2 | 31.9 | 2833 | 51 | 500 | A | A | |
| 275/60R20 | 115H | 10.3 | 8.0J | 11 | 33 | 2679 | 44 | 500 | A | A | |
| 22″ | 305/40R22 XL | 114V | 10.3 | 11.0J | 12.3 | 31.6 | 2337 | 51 | 500 | A | A |
| 285/45R22 | 114H | 10.3 | 9.5J | 11.2 | 32.1 | 2601 | 44 | 500 | A | A | |
| 305/45R22 XL | 118V | 10.3 | 10.0J | 11.9 | 32.8 | 2910 | 51 | 500 | A | A | |
| 24″ | 305/35R24 XL | 112V | 10.3 | 11.0J | 12.3 | 32 | 2469 | 51 | 500 | A | A |
* We reserve the rights of final interpretation and modification
