Description
| Size | LR/PR | Tread Depth (32ND) | Service Index | Standard Rim | Overall Diameter (inch) | Section Width (inch) | Max. Load Capacity at Cold Inflation Pressure | Revs per Mile | Static Loaded Radius (inch) | |||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Single | Dual | |||||||||||
| (LBS) | (PSI) | (LBS) | (PSI) | |||||||||
| 215/75R17.5 | H/16 | 16 | 135/133J | 6.00 | 30.2 | 8.3 | 4805 | 123 | 4540 | 123 | 688 | 14.1 |
| 235/75R17.5 | H/16 | 16 | 143/141J | 6.75 | 31.3 | 9.1 | 6005 | 128 | 5675 | 128 | 664 | 14.6 |
| 225/70R19.5 | G/14 | 16 | 128/126M | 6.75 | 31.9 | 8.9 | 3970 | 110 | 3750 | 110 | 651 | 15.0 |
| 245/70R19.5 | G/14 | 17 | 133/131M | 7.50 | 33.0 | 9.8 | 4540 | 110 | 4300 | 110 | 629 | 15.5 |
| 245/70R19.5 | H/16 | 17 | 136/134M | 7.50 | 33.0 | 9.8 | 4940 | 120 | 4675 | 120 | 629 | 15.5 |
| 265/70R19.5 | G/14 | 17 | 137/134M | 7.50 | 34.1 | 10.3 | 5070 | 110 | 4675 | 110 | 609 | 16.0 |
| 265/70R19.5 | H/16 | 17 | 140/138M | 7.50 | 34.1 | 10.3 | 5510 | 112 | 5200 | 112 | 609 | 16.0 |
| 11R22.5 | G/14 | 22 | 144/142L | 8.25 | 41.5 | 11.0 | 6175 | 105 | 5840 | 105 | 500 | 19.3 |
| 11R22.5 | H/16 | 22 | 146/143L | 8.25 | 41.5 | 11.0 | 6610 | 120 | 6005 | 120 | 500 | 19.3 |
| 255/70R22.5 | H/16 | 18 | 140/137M | 7.50 | 36.5 | 10.0 | 5510 | 120 | 5070 | 120 | 569 | 17.1 |
| 275/70R22.5 | H/16 | 19 | 148/145L | 8.25 | 37.7 | 10.8 | 6940 | 130 | 6395 | 130 | 557 | 17.6 |
| 295/75R22.5 | G/14 | 22 | 144/141L | 9.00 | 40.2 | 11.7 | 6175 | 110 | 5675 | 110 | 520 | 18.8 |
| 11R24.5 | G/14 | 22 | 146/143L | 8.25 | 43.5 | 11.0 | 6610 | 105 | 6005 | 105 | 477 | 20.3 |
| 11R24.5 | H/16 | 22 | 149/146L | 8.25 | 43.5 | 11.0 | 7160 | 120 | 6610 | 120 | 477 | 20.3 |
| 285/75R24.5 | G/14 | 22 | 144/141L | 8.25 | 41.3 | 11.1 | 6175 | 110 | 5675 | 110 | 503 | 19.4 |
* We reserve the rights of final interpretation and modification
